db - Formula

The decibel of 𝑃₁ in reference to 𝑃₂ is defined by the following formula:

bd - Chart

dB	Power ratio		Amplitude ratio
100	10000000000		100000
90	1000000000		31623
80	100000000		10000
70	10000000		3162
60	1000000		1000
50	100000		316	.2
40	10000		100
30	1000		31	.62
20	100		10
10	10		3	.162
6	3	.981 ≈ 4	1	.995 ≈ 2
3	1	.995 ≈ 2	1	.413 ≈ √2
1	1	.259	1	.122
0	1		1
−1	0	.794	0	.891
−3	0	.501 ≈ 1⁄2	0	.708 ≈ √1⁄2
−6	0	.251 ≈ 1⁄4	0	.501 ≈ 1⁄2
−10	0	.1	0	.3162
−20	0	.01	0	.1
−30	0	.001	0	.03162
−40	0	.0001	0	.01
−50	0	.00001	0	.003162
−60	0	.000001	0	.001
−70	0	.0000001	0	.0003162
−80	0	.00000001	0	.0001
−90	0	.000000001	0	.00003162
−100	0	.0000000001	0	.00001
An example scale showing power ratios x, amplitude ratios √x, and dB equivalents 10 log₁₀x.
